WINDOWS INTERNET PROGRAMMING {part 2}

=================================================







   WRITTEN BY                 [ <a href="mailto:cos125@hotmail.com">cos125@hotmail.com</a>                :E-MAIL    ]

           <a href="mailto:cos125@hotmail.com">BINARY RAPE</a>        [ 114603188                         :ICQ#      ]

                              [ <a href="http://www.geocities.com/wininetprogram">www.geocities.com/wininetprogram</a>  :WEB SITE  ]

                              [ <a href="http://blacksun.box.sk">http://blacksun.box.sk</a>            :TURORIALS ]











Thanks to cyberwolf for letting me write this and BSRF for releasing it.











<br>

<p>Disclaimer

<p>None of the information or code in this tutorial is meant to be used

against others

<br>or to purposely damage computer systems and/or cause any loss of or

damage to property.

<p>Further more, neither myself or any other contributor to, or member

of, the Blacksun

<br>research Facility (BSRF) can be held responsible for damage or loss

of property to

<br>computer systems as a result of this tutorial.

<p>In this tutorial the code is provided as a learning aid so you can see

how its done

<br>its not meant for you to use against yourself or others.

<p>If you don't agree with any of this then please stop reading......&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

now!

<br>

<p>CONTENTS

<br>

<p>1.&nbsp; <a href="#1">Introduction</a>

<br>2.&nbsp; <a href="#2">UNIX and Windows</a>

<br>3.&nbsp; <a href="#3">Error Codes</a>

<br>4.&nbsp; <a href="#4">Port Numbers</a>

<br>5.&nbsp; <a href="#5">Include Files</a>

<br>&nbsp;&nbsp; -<a href="#5.1"> 5.1 socket()</a>

<br>&nbsp;&nbsp;&nbsp; -<a href="#5.2">5.2 bind()</a>

<br>&nbsp;&nbsp;&nbsp; -<a href="#5.3">5.3 connect()</a>

<br>&nbsp;&nbsp;&nbsp; -<a href="#5.4">5.4 listen()</a>

<br>&nbsp;&nbsp;&nbsp; -<a href="#5.5">5.5 accept()</a>

<br>&nbsp;&nbsp;&nbsp; -<a href="#5.6">5.6 gethostname()</a>

<p>6.&nbsp; <a href="#6">Common Functions</a>

<br>7.&nbsp;<a href="#7"> Renamed Functions</a>

<br>8.&nbsp; <a href="#8">Blocking Routines</a>

<br>9.&nbsp; <a href="#9">Additional Functions</a>

<br>10. <a href="#10">Porting Code</a>

<br>&nbsp;&nbsp;&nbsp; -10.1 <a href="#10.1">DNS Program</a>

<br>&nbsp;&nbsp;&nbsp; -10.2 <a href="#10.2">Streaming Server</a>

<br>&nbsp;&nbsp;&nbsp; -10.3 Streaming Client

<p>11. <a href="#11">Planning</a>

<br>12. <a href="#12">Last Words</a>

<p>&nbsp;&nbsp;&nbsp; APPENDIXES

<p>&nbsp;&nbsp;&nbsp; A - <a href="#appxA">The Compiler</a>

<p>______________________

<br>1.0<a NAME="1"></a> INTRODUCTION

<br>&nbsp;

<p>In the last part in this series of tutorials I discussed windows sockets

programming using

<br>the winsock API and in that document I mentioned that the windows Sockets

implementation is

<br>based on the Berkeley Sockets idea, therefore socket programming on

systems such as UNIX

<br>and Linux, which are also based on the Berkeley API would be quiet

similar. This aids us

<br>in porting from platform to platform, making it easy to move whole

programs from UNIX to

<br>windows in a very short time.

<p>This tutorial will discuss and illustrate the differences in code and

functions between the

<br>platforms and sample source code and applications will be provided

to show how to port the

<br>applications piece by piece.

<p>I suggest that you first read Part 1 in this series of tutorials and

also Bracaman's basic

<br>UNIX sockets tutorial, also available from blacksun.box.sk and also

from code.box.sk.

<p>Any add on information for this tutorial and updates are available as

usual from:

<br>http://www.geocities.com/winnetprogram.

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>2.0&nbsp;<a NAME="2"></a>UNIX AND WINDOWS

<br>=====================

<p>Unix and Windows handle sockets differently, UNIX treats sockets the

same as a file handle

<br>which is a small integer while in windows it is an unsigned type called

SOCKET.

<p>So from the start UNIX and windows actually think of there respective

sockets differently.

<p>To best explain the differences the following is an exert from bracamans

tutorial and

<br>describes sockets from the Unix point of view:

<br>&nbsp;

<p>"In a very simple way, a socket is a way to talk to other computer.

<p>To be more precise, it's a way to talk to other computers using standard

Unix file

<br>descriptors.

<p>In Unix, every I/O actions are done by writing or reading to a file

descriptor. A file

<br>descriptor is just an integer associated with an open file and it can

be a network connection,

<br>a terminal, or something else."

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>3.0&nbsp;<a NAME="3"></a>ERROR CODES

<br>=======================================

<p>In UNIX error codes are available trough the errno variable. In windows

we use the function

<br>WSAGetLastError() to obtain these error codes.

<br>&nbsp;

<p>_________________________

<p>4.0&nbsp;<a NAME="4"></a>PORT NUMBERS

<br>=======================================

<p>In both Unix and Windows you define the port numbers by entering the

destination port number

<br>as a parameter to the function htons(), however in winsock.h several

port numbers are defined

<br>for common ports so that you can also use these.

<p>The following is a list of the default names and there relative port

numbers:

<br>

<pre>



1.  IPPORT_ECHO             -  7

2.  IPPORT_DISCARD          -  9

3.  IPPORT_SYSTAT           -  11

4.  IPPORT_DAYTIME          -  13

5.  IPPORT_NETSTAT          -  15

6.  IPPORT_FTP              -  21

7.  IPPORT_TELNET           -  23

8.  IPPORT_SMTP             -  25

9.  IPPORT_TIMESERVER       -  37

10. IPPORT_NAMESERVER       -  42

11. IPPORT_WHOIS            -  43

12. IPPORT_MTP              -  57

</pre>

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>5.0&nbsp;<a NAME="5"></a>INCLUDE FILES

<br>=======================================

<p>In UNIX there are a number of include files to use in socket programming,

following is a

<br>list of these functions and related #include files:

<br>&nbsp;

<p>5.1&nbsp;<a NAME="5.1"></a>socket()

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/types.h>&nbsp; ]

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/socket.h> ]

<br>&nbsp;

<p>5.2&nbsp;<a NAME="5.2"></a>bind()

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/types.h>&nbsp; ]

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/socket.h> ]

<br>&nbsp;

<p>5.3&nbsp;<a NAME="5.3"></a>connect()

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/types.h>&nbsp; ]

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/socket.h> ]

<br>&nbsp;

<p>5.4&nbsp;<a NAME="5.4"></a>listen()

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/types.h>&nbsp; ]

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/socket.h> ]

<br>&nbsp;

<p>5.5&nbsp;<a NAME="5.5"></a>accept()

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; [ #include &lt;sys/socket.h> ]

<p>5.6&nbsp;<a NAME="5.6"></a>gethostname()

<p>&nbsp; [ #include &lt;netdb.h>&nbsp;&nbsp; ]

<br>&nbsp;

<br>&nbsp;

<p>You will need some general socket include files also in UNIX programming:

<p>#include &lt;netinet/in.h>

<br>#include &lt;arpa/inet.h>

<br>&nbsp;

<p>Your average list of include files at the top of a UNIX socket program

would therefore

<br>look something like the following:

<p>#include &lt;sys/types.h>

<br>#include &lt;sys/socket.h>

<br>#include &lt;netdb.h>

<br>#include &lt;netinet/in.h>

<br>#include &lt;arpa/inet.h>

<br>&nbsp;

<p>In windows the header file for socket and internet programming is contained

in windows.h,

<br>therefore the top of a windows socket programming would look like this:

<p>#include &lt;windows.h>

<p>The name of the header file for windows socket programming is winsock.h

and including

<br>this file in your project as well wont cause any errors of course but

there’s just no need.

<p>Windows programs also need to be linked to the file Wsock32.lib before

they can be

<br>compiled.

<p>Consult your compilers documents for further information on this or

proceed to Appendix 1

<br>- The compiler.

<p>

<hr SIZE=1 WIDTH="70%">

<br>

<p>6.0<a NAME="6"></a>COMMON FUNCTIONS

<br>=======================================

<p>Both Unix and Windows sockets have a set of functions common to both

platforms. These are

<br>mostly the functions dealing with TCP and UDP and all conversion functions

and structures

<br>are the same for both platforms.

<p>For example htons() and inet_addr() are the same on both platforms,

also so is the

<br>structures sockaddr and sockaddr_in.

<br>&nbsp;

<p>Here is a list of common functions.

<p>1.&nbsp; Socket()

<p>2.&nbsp; Bind()

<p>3.&nbsp; Listen()

<p>4.&nbsp; Connect()

<p>5.&nbsp; Accept()

<p>6.&nbsp; Send()

<p>7.&nbsp; Recv()

<p>8.&nbsp; Sendto()

<p>9.&nbsp; Recvfrom()

<p>10. Gethostname()

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>7.0<a NAME="7"></a> RENAMED FUNCTIONS

<br>=======================================

<p>There are some functions which exist in both windows and UNIX socket

programming but

<br>during the conversion the names have changed slightly.

<p>The following table contains a comparison of renamed functions in windows

and UNIX.<br>

<pre>



+===============+==================+

| Unix Function | Windows Function |

+===============+==================+

|    close()    |   closesocket()  |

+---------------+------------------+

|    ioctl()    |   ioctlsocket()  |

+---------------+------------------+

|     read()    |      recv()      |

+---------------+------------------+

|    write()    |      send()      |

+---------------+------------------+

</pre>

<p>&nbsp;FIG 1. - Comparison of Windows and Unix Socket functions.

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>8.0<a NAME="8"></a> BLOCKING ROUTINES

<br>=======================================

<p>In windows you can use blocking routines but they are not recommended.

In windows 3.1

<br>using the event driven paradigm it is possible to have a blocked operation

disturbed

<br>by other event driven activity.

<p>Soon you will not be able to have blocking routines in Winsock applications

so it is

<br>not recommended you use them at all in this scenario as this would

limit distribution

<br>possibilities.

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>9.0&nbsp;<a NAME="9"></a>ADDITIONAL FUNCTIONS

<br>=======================================

<p>In windows there are some functions which aren't seen in UNIX sockets.

In every

<br>windows socket program you must call WSAStarup() before you can call

any socket

<br>functions or use any code.

<p>Additionally every WSAStartup() function has a corresponding WSACleanup()

which

<br>shuts down the Winsock and cleans up after us.

<p>Every Windows socket program must contain both of these functions.

<br>&nbsp;

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<p>10.0&nbsp;<a NAME="10"></a>PORTING CODE

<br>=======================================

<p>Now that we have discussed the different parts of the program in Unix

and its relevant

<br>Windows parts we can look at some real code.

<br>&nbsp;

<br>&nbsp;

<p>[ 10.1 ]<a NAME="10.1"></a> DNS PROGRAM

<p>The first program we come across is Bracamans DNS application. Here’s

the Unix Code.

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;stdio.h>

<br>#include &lt;netdb.h>&nbsp;&nbsp; /* This is the header file needed

for gethostbyname() */

<br>#include &lt;sys/types.h>

<br>#include &lt;sys/socket.h>

<br>#include &lt;netinet/in.h>

<br>&nbsp;

<p>int main(int argc, char *argv[])

<br>{

<br>&nbsp; struct hostent *he;

<p>&nbsp; if (argc!=2){

<br>&nbsp;&nbsp;&nbsp;&nbsp; printf("Usage: %s &lt;hostname>\n",argv[0]);

<br>&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((he=gethostbyname(argv[1]))==NULL){

<br>&nbsp;&nbsp;&nbsp;&nbsp; printf("gethostbyname() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; printf("Hostname : %s\n",he->h_name);&nbsp; /* prints the hostname

*/

<br>&nbsp; printf("IP Address: %s\n",inet_ntoa(*((struct in_addr *)he->h_addr)));

/* prints IP address */

<br>}

<br>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<br>&nbsp;

<p>This is a very small but still a very useful program. If we attempt

to compile this

<br>right away under Microsoft Visual C++ We will get an error saying that

it can not

<br>find an include file, so our first duty is to remove all of the Unix

Socket include

<br>files and replace them with the line:

<p>#include &lt;windows.h>

<p>remembering to leave stdio.h right where it is.

<br>When I tried compiling it now I got several more errors so I changed

the

<br>main() fuction from what it is above to:

<p>void main(int argc, char **argv) and the program then compiled.

<p>However I then got several linker errors. Remember when socket programming

on windows

<br>you must link to the file Wsock32.lib.

<p>After I linked to the proper .lib file the program compiles perfectly,

without the

<br>need to touch a single line of the socket code!!

<p>This is how compatible different platforms can be with socket code,

however this is a

<br>very small program and this is not usually the case. The following

is the windows

<br>source code for the port of Bracamans DNS program.

<p>Remember you will get an error unless you include WSAStartup() and WSACleanup()!!

<br>&nbsp;

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;windows.h>

<br>#include &lt;stdio.h>

<p>int main(int argc, char *argv[])

<br>{

<p>&nbsp; WSADATA&nbsp; wsdata;

<p>&nbsp; WSAStartup(0x0101,&amp;wsdata);

<p>&nbsp; struct hostent *he;

<p>&nbsp; if (argc! = 2)

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp;&nbsp; printf("Usage: %s hostname\n",argv[0]);

<br>&nbsp;&nbsp;&nbsp;&nbsp; return -1;

<br>&nbsp; }

<p>&nbsp; if ((he = gethostbyname(argv[1])) == NULL)

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp;&nbsp; printf("gethostbyname() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp; return -1;

<br>&nbsp; }

<p>&nbsp; printf("Hostname : %s\n",he->h_name);&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* prints the hostname */

<br>&nbsp; printf("IP Address: %s\n",inet_ntoa(*((struct in_addr *)he->h_addr)));&nbsp;

/* prints IP address */

<p>&nbsp; WSACleanup();

<br>&nbsp; return -1;

<p>}

<br>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<p>This program has almost as few lines as the UNIX alternative and requires

practically

<br>no porting at all!

<p>Like I said you wouldn’t usually have a program that runs on windows

with such little altering.

<br>Lets discuss porting Bracamans TCP streaming server.

<br>&nbsp;

<p>[ 10.2 ]&nbsp;<a NAME="10.2"></a>STREAMING SERVER

<br>&nbsp;

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;stdio.h>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* These are the usual header files */

<br>#include &lt;sys/types.h>

<br>#include &lt;sys/socket.h>

<br>#include &lt;netinet/in.h>

<br>&nbsp;

<p>#define PORT 3550&nbsp;&nbsp; /* Port that will be opened */

<br>#define BACKLOG 2&nbsp;&nbsp; /* Number of allowed connections */

<p>main()

<br>{

<br>&nbsp;

<br>&nbsp; int fd, fd2; /* file descriptors */

<p>&nbsp; struct sockaddr_in server; /* server's address information */

<br>&nbsp; struct sockaddr_in client; /* client's address information */

<p>&nbsp; int sin_size;

<br>&nbsp;

<p>&nbsp; if ((fd=socket(AF_INET, SOCK_STREAM, 0)) == -1 ){&nbsp; /* calls

socket() */

<br>&nbsp;&nbsp;&nbsp; printf("socket() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; server.sin_family = AF_INET;

<br>&nbsp; server.sin_port = htons(PORT);&nbsp;&nbsp; /* Remember htons()

from "Conversions" section? =) */

<br>&nbsp; server.sin_addr.s_addr = INADDR_ANY;&nbsp; /* INADDR_ANY puts

your IP address automatically */

<br>&nbsp; bzero(&amp;(server.sin_zero),8); /* zero the rest of the structure

*/

<p>&nbsp;

<br>&nbsp; if(bind(fd,(struct sockaddr*)&amp;server,sizeof(struct sockaddr))==-1){

/* calls bind() */

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("bind() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if(listen(fd,BACKLOG) == -1){&nbsp; /* calls listen() */

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("listen() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>while(1){

<br>&nbsp; sin_size=sizeof(struct sockaddr_in);

<br>&nbsp; if ((fd2 = accept(fd,(struct sockaddr *)&amp;client,&amp;sin_size))==-1){

/* calls accept() */

<br>&nbsp;&nbsp;&nbsp; printf("accept() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<br>&nbsp;

<br>&nbsp; printf("You got a connection from %s\n",inet_ntoa(client.sin_addr)

); /* prints client's IP */

<br>&nbsp;

<br>&nbsp; send(fd2,"Welcome to my server.\n",22,0); /* send to the client

welcome message */

<br>&nbsp;

<br>&nbsp; close(fd2); /*&nbsp; close fd2 */

<br>}

<br>}

<p>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<br>&nbsp;

<p>Well lets try and compile shall we...

<br>&nbsp;

<p>Straight away we should clear the obvious problems, link to Winsock32.lib

and

<br>only include windows.h and stdio.h.

<p>Having done so we receive 2 errors, the first pertains to bzero which

we do not

<br>have in our little program so we are going to just remove the line

that contains

<br>it. Once we do so we now have only 1 error, woohoo!

<p>This error tells us that the function close() is not a valid identifier

which is

<br>what I said earlier, close() has been replaced by closesocket() in

windows so we

<br>change that as well to closesocket().

<p>We run this program and we recieve a socket error :(. But remember we

never entered

<br>WSAStartup() and WSACleanup() in this program so we have to do that

first and then

<br>our program will work :).

<p>If you run the program the command prompt should remain blank, just

leave the program

<br>as it is now and move onto the next section to figure out where to

go from here!!

<p>First of course here’s the Windows code for the port ;).

<br>&nbsp;

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;stdio.h>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* These are the usual header files */

<br>#include &lt;windows.h>

<br>&nbsp;

<p>#define PORT 3550&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*

Port that will be opened */

<br>#define BACKLOG 2&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*

Number of allowed connections */

<p>main()

<br>{

<br>&nbsp; WSADATA&nbsp; wsdata;

<p>&nbsp; WSAStartup(0x0101,&amp;wsdata);

<p>&nbsp; int fd, fd2;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* file

descriptors */

<br>&nbsp;

<p>&nbsp; struct sockaddr_in server;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* server's

address information */

<br>&nbsp; struct sockaddr_in client;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*

client's address information */

<p>&nbsp; int sin_size;

<br>&nbsp;

<p>&nbsp; if ((fd=socket(AF_INET, SOCK_STREAM, 0)) == -1 )&nbsp;&nbsp;&nbsp;

/* calls socket() */

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp; printf("socket() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; server.sin_family&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; = AF_INET;

<br>&nbsp; server.sin_port&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

= htons(PORT);&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* Remember htons() from "Conversions"

section? =) */

<br>&nbsp; server.sin_addr.s_addr&nbsp; = INADDR_ANY;&nbsp;&nbsp;&nbsp;&nbsp;

/* INADDR_ANY puts your IP address automatically */

<p>&nbsp;

<br>&nbsp; if(bind(fd,(struct sockaddr*)&amp;server,sizeof(struct sockaddr))==-1)&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* calls bind() */

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("bind() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<br>&nbsp;

<p>&nbsp; if(listen(fd,BACKLOG) == -1)&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*

calls listen() */

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("listen() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<br>&nbsp;

<p>while(1)

<br>&nbsp; {

<br>&nbsp; sin_size=sizeof(struct sockaddr_in);

<p>&nbsp; if ((fd2 = accept(fd,(struct sockaddr *)&amp;client,&amp;sin_size))

== -1)&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* calls accept()

*/

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("accept() error\n");

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<br>&nbsp;

<br>&nbsp; printf("You got a connection from %s\n",inet_ntoa(client.sin_addr)

);&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* prints client's IP */

<br>&nbsp;

<br>&nbsp; send(fd2,"Welcome to my server.\n",22,0);&nbsp;&nbsp;&nbsp;

/* send to the client welcome message */

<br>&nbsp;

<br>&nbsp; closesocket(fd2);&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*&nbsp;

close fd2 */

<p>&nbsp;

<br>&nbsp;&nbsp; WSACleanup();

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; return -1;

<br>}

<br>}

<p>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<br>&nbsp;

<p>[ 10.3 ] STREAMING CLIENT

<br>&nbsp;

<br>&nbsp;

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;stdio.h>

<br>#include &lt;sys/types.h>

<br>#include &lt;sys/socket.h>

<br>#include &lt;netinet/in.h>

<br>#include &lt;netdb.h>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /*

netbd.h is needed for struct hostent =) */

<p>#define PORT 3550&nbsp;&nbsp; /* Open Port on Remote Host */

<br>#define MAXDATASIZE 100&nbsp;&nbsp; /* Max number of bytes of data

*/

<p>int main(int argc, char *argv[])

<br>{

<br>&nbsp; int fd, numbytes;&nbsp;&nbsp; /* files descriptors */

<br>&nbsp; char buf[MAXDATASIZE];&nbsp; /* buf will store received text

*/

<br>&nbsp;

<br>&nbsp; struct hostent *he;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* structure that will get information about remote host */

<br>&nbsp; struct sockaddr_in server;&nbsp; /* server's address information

*/

<p>&nbsp; if (argc !=2) {&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* this is

used because our program will need one argument (IP) */

<br>&nbsp;&nbsp;&nbsp; printf("Usage: %s &lt;IP Address>\n",argv[0]);

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((he=gethostbyname(argv[1]))==NULL){ /* calls gethostbyname()

*/

<br>&nbsp;&nbsp;&nbsp; printf("gethostbyname() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((fd=socket(AF_INET, SOCK_STREAM, 0))==-1){&nbsp; /* calls

socket() */

<br>&nbsp;&nbsp;&nbsp; printf("socket() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; server.sin_family = AF_INET;

<br>&nbsp; server.sin_port = htons(PORT); /* htons() is needed again */

<br>&nbsp; server.sin_addr = *((struct in_addr *)he->h_addr);&nbsp; /*he->h_addr

passes "*he"'s info to "h_addr" */

<br>&nbsp; bzero(&amp;(server.sin_zero),8);

<p>&nbsp; if(connect(fd, (struct sockaddr *)&amp;server,sizeof(struct sockaddr))==-1){

/* calls connect() */

<br>&nbsp;&nbsp;&nbsp; printf("connect() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((numbytes=recv(fd,buf,MAXDATASIZE,0)) == -1){&nbsp; /* calls

recv() */

<br>&nbsp;&nbsp;&nbsp; printf("recv() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; buf[numbytes]='\0';

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("Server Message: %s\n",buf); /*

it prints server's welcome message =) */

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; close(fd);&nbsp;&nbsp; /* close fd =)

*/

<br>}

<p>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<p>That’s the source code for the Unix client and of course the windows

one doesn't

<br>look very different.

<br>&nbsp;

<p>/* &lt;---- SOURCE CODE STARTS HERE ----> */

<p>#include &lt;windows.h>

<br>#include &lt;stdio.h>

<p>#define PORT 3550&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* Open Port on

Remote Host */

<br>#define MAXDATASIZE 100&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* Max number

of bytes of data */

<p>int main(int argc, char *argv[])

<br>{

<br>&nbsp; WSADATA&nbsp; wsdata;

<p>&nbsp; WSAStartup(0x0101,&amp;wsdata);

<p>&nbsp; int fd, numbytes;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; /* files descriptors

*/

<br>&nbsp; char buf[MAXDATASIZE];&nbsp;&nbsp;&nbsp;&nbsp; /* buf will store

received text */

<br>&nbsp;

<br>&nbsp; struct hostent *he;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* structure that will get information about remote host */

<br>&nbsp; struct sockaddr_in server;&nbsp;&nbsp;&nbsp; /* server's address

information */

<p>&nbsp; if (argc !=2) {&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* this is used because our program will need one argument (IP) */

<br>&nbsp;&nbsp;&nbsp; printf("Usage: %s &lt;IP Address>\n",argv[0]);

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((he=gethostbyname(argv[1])) == NULL){ /* calls gethostbyname()

*/

<br>&nbsp;&nbsp;&nbsp; printf("gethostbyname() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((fd=socket(AF_INET, SOCK_STREAM, 0))==-1) /* calls socket()

*/

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp; printf("socket() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; server.sin_family&nbsp; = AF_INET;

<br>&nbsp; server.sin_port&nbsp;&nbsp;&nbsp; = htons(PORT);&nbsp;&nbsp;&nbsp;&nbsp;

/* htons() is needed again */

<br>&nbsp; server.sin_addr&nbsp;&nbsp;&nbsp; = *((struct in_addr *)he->h_addr);&nbsp;&nbsp;

/*he->h_addr passes "*he"'s info to "h_addr" */

<br>&nbsp;

<p>&nbsp; if(connect(fd, (struct sockaddr *)&amp;server,sizeof(struct sockaddr))==-1)&nbsp;

/* calls connect() */

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp; printf("connect() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp; if ((numbytes=recv(fd,buf,MAXDATASIZE,0)) == -1)&nbsp;&nbsp;&nbsp;

/* calls recv() */

<br>&nbsp; {

<br>&nbsp;&nbsp;&nbsp; printf("recv() error\n");

<br>&nbsp;&nbsp;&nbsp; exit(-1);

<br>&nbsp; }

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; buf[numbytes] = '\0';

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; printf("Server Message: %s\n",buf);&nbsp;&nbsp;&nbsp;

/* it prints server's welcome message =) */

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; closesocket(fd);&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;&nbsp;

/* close fd =) */

<p>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; WSACleanup();

<br>&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; return -1;

<br>}

<p>/* &lt;---- SOURCE CODE ENDS HERE ----> */

<br>&nbsp;

<p>There’s actually no real difference with this port and the last. The

same lines are

<br>changed and the same functions are included as before.

<p>Start the program by switching to its directory on the command line

and typing

<p>streamclient.exe local host

<p>Where streamclient.exe is the name of the stream client program we just

ported

<br>naturally :).

<p>Just make sure that the previous example, the streaming server is running

and

<br>your away. The screen will print the line "Welcome to my server." Congratulations

<br>you’ve ported your first Unix Socket client and server to windows and

you received

<br>a line of text back from your own server :).

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<br>&nbsp;

<p>11.0&nbsp;<a NAME="11"></a>Planning

<br>=======================================

<p>When porting its probably best to go trough things like a check list

before attempting

<br>to compile the bloody thing. Here’s a list of some recommendations

to run trough first.

<p>1. Replace all network header files with windows.h or winsock.h.

<br>2. Make sure to add WSAStartup() and WSACleanup() before and after

the code.

<br>3. Replace functions such as close() and ioctl() with windows counterparts.

<br>4. Take care of problems such as bzero() and add any windows specific

features like

<br>&nbsp;&nbsp; default ports.

<br>&nbsp;

<p>With so few and simple operations like this it would be pretty damn

easy to write

<br>a program that performs these actions for you, I doubt it would be

complete but hey

<br>it would save you a lot of time in the long run, especially with larger

applications.

<p>

<hr SIZE=1 WIDTH="70%">

<br>&nbsp;

<br>&nbsp;

<p>12.0<a NAME="12"></a> LAST WORDS

<br>==============

<p>Well that’s it for this tutorial, or at least this part of it. More

parts are planned so

<br>hopefully you should see them on blacksun soon :). This part covered

the basics of

<br>windows programming, there was no point in writing about UNIX programming

as bracaman

<br>has released a very good tutorial on basic UNIX sockets programming

which is available

<br>from blacksun.box.sk and code.box.sk.

<p>I will be discussing Unix sockets again however in the next part of

this tutorial but

<br>mostly in a porting sense. To see what’s planned for future parts so

far just look down :).

<br>&nbsp;

<p>Part 2. -&nbsp; GENERAL SOCKETS&nbsp; - Porting to windows and cross

platform code.

<br>Part 3.&nbsp; -&nbsp; RAW Sockets&nbsp;&nbsp;&nbsp;&nbsp; - Have more

control over packets with raw sockets.

<br>Part 4.&nbsp; -&nbsp; ADVANCED&nbsp;&nbsp;&nbsp;&nbsp;&nbsp; - A real

world example by building an internet communication suite.

<br>Part 5.&nbsp; -&nbsp; FINISHING OFF&nbsp;&nbsp;&nbsp; - Putting it

all together in one big program.

<p>So that’s what’s still to come, but I may change some of these future

tutorials at any

<br>time before there released if I do so it will be to improve the series

in my view and

<br>remember send me comments and suggestions and your ideas might also

change the layout

<br>of following tutorials.

<br>&nbsp;

<p>Well thank you for reading this tutorial and visit my website to keep

up to date with

<br>the series and for add on code and articles to the series.

<p>- BR ;)

<br>&nbsp;

<p>*<a NAME="final"></a>FINAL NOTE*

<p>Id really like to thank Bracaman for everything including allowing me

to use code from

<br>his tutorial and please remember that this tutorial should be read

with his (after his

<br>1 even :P), so thanks for everything Bracaman it helped so much :).

<p>

<hr SIZE=1 WIDTH="70%">

<p>APPENDIX A - THE COMPILER<a NAME="appxA"></a>

<br>

<p>All of the programs in this tutorial have been tested under Microsoft

Visual C++ 6.0,

<br>im running Windows 2000 Professional edition and I have an Intel Pentium

2.

<p>To set up the compiler for Winsock programming you need to link Wsock32.lib

to your project.

<br>Under Visual C++ do the following.

<p>1. Select the File view tab.

<br>2. Right Click the files menu and go to Settings.

<br>3. Select the Link tab in Project Settings.

<br>4. Add Wsock32.lib to the list of .lib files and press ok.

<p>The winsock.h header file is included in windows.h so don’t worry about

that.

<p>

<hr SIZE=1 WIDTH="70%">

</body>

</html>

0 comments:

Comment here / Ask your Query !!
